Analog Outputs

The line level outputs of the M-32 DA Pro II operate at +13 dBu, +19 dBu, or +24 dBu. Each individual channel has its own line level setting, which can be adjusted remotely. Additionally, channels can be muted globally or individually.

In its default state, no routing exists between the digital inputs and the analog outputs. Each group of four consecutive outputs can receive its signal from any digital input that is connected and synchronized.

At all sample rates, the converters operate with short delay IIR filters. At single speed, a short delay 'sharp' filter is used to ensure linear frequency response. At double and quad speed, a short delay 'slow' filter is used to optimize the transient response of the M-32 DA Pro II while maintaining linear frequency response in the audible range.

The resulting latencies are 7 samples at single speed and 5.5 samples at sample rates > 48 kHz.

Adjusting the Output Line Level

To adjust the output line level:

  1. Open the Analog Output Configuration tab in the OUTPUT section.

    wDA 310 2T 1

  2. Initially, the cursor will highlight all output channels. To accept this, rotate the encoder to move the cursor to the current reference level.

  3. Alternatively, pressing the encoder on the channel strip allows the selection of an individual channel.

    wDA2 310 2T 2

    wAL co 1

    Cursor (current channel)

    wAL co 2

    Input Reference Level

  4. Move the cursor to the current line level and push it.

  5. Rotate the encoder to change the setting and confirm by pushing the encoder again.

To adjust the output line level on the web remote:

  1. Select an analog output channel by clicking the corresponding channel strip. The channel strip turns blue.

  2. (optional) Click and drag left or right to select multiple channels.

    wAL 310 2T 3

  3. Press one of the buttons for +13 dBu, +19 dBu or +24 dBu below the selection. The selected value is shown within the level meter.

Mute Analog Outputs

To mute an individual output channel on the device:

  1. Open the Analog Output Configuration tab in the OUTPUT section

    wAL 310 3T 1

  2. Initially, the cursor will highlight all output channels. Press the encoder, then rotate the encoder to move the cursor to the channel that should be muted.

    wDA2 310 3T 2

    wAL co 1

    Cursor (current channel)

    wAL co 2

    Channel Mute

  3. Move the cursor to Mute Toggle and push it.

To mute an output channel using the web remote:

  1. Select an analog output channel by clicking the corresponding channel strip. The channel strip turns blue.

  2. (optional) Click and drag left or right to select multiple channels.

    wAL 310 2T 3

  3. Toggle the Mute switch. The status is reflected with a red M in the corresponding level meters.
