Use of the Display and Encoder

The M-32 DA Pro II-D can be controlled directly at the unit. For this purpose, a display and an encoder provide access to all features.

Control Section

  • Rotating the encoder when the standby screen is shown highlights one of four sections.

  • Pushing the encoder when the screen is idle activates the previously active tab.

  • Pushing the encoder when a section is highlighted opens the corresponding section.

Sections

All control items are categorized into four sections:

  • STATE for general settings

  • INPUT for audio input related settings

  • OUTPUT for audio output related settings and routing

  • CLOCK for digital clock related settings

How to navigate
To access the INPUT section:

  1. Rotate the encoder to highlight the "STATE" section

  2. Rotate the encoder to highlight the "INPUT" section

  3. Push the encoder to open the "INPUT" section.

Tabs

The STATE, INPUT and OUTPUT sections are further divided into tabs, which are shown when the section is opened. Upon opening one of the four sections, a white cursor with a surrounding blue line is shown to navigate between tabs and settings.

Cursor on PSU tab in Input Section

To close the section, move the cursor onto the minimize-icon Minimize Icon and confirm by pressing the encoder.
