Replacing the Channel Labels

No tools are required to replace the channel labels. All 32 labels are printed or written onto a single sheet.

Perform the following steps to replace the labels:
  1. On the left side of the cover, place your fingertip into the recess and gently pull the cover towards you.

    w32 020 3T 1
  2. Remove the current label sheet that is held between cover and device.

  3. Place a new label sheet onto the cover.

  4. Put the cover back into its place, aligning the centered metal plate first. It snaps into place magnetically.

It is possible to prepare your own paper cutouts in case you frequently need to label the fields. A PDF template is available upon request from your support. When choosing the paper type, ensure that its thickness allows sufficient light to pass through.
